Newly Released: ASPO for AutoCAD Plant 3D — Automate Fabrication Drawings and Spool Workflows
— Keep 3D Data Connected from Design through Fabrication
About the Webinar
3D plant design has made engineering data more structured and connected. But once a project moves from detailed design into fabrication, many teams still rely on manual processes to create fabrication drawings, define Shop and Field welds, assign spool and weld numbers, and keep drawings aligned with the latest 3D model.
As project designs change, maintaining consistency across the model, drawings, and fabrication information can require significant engineering time and create additional opportunities for rework.
ASPO is an add-in suite for Autodesk AutoCAD Plant 3D designed to automate and streamline these fabrication-related workflows while keeping information connected to the 3D model.
In this webinar, we will introduce two ASPO solutions through practical workflows and demonstrations.
ASPO Support Fab helps automate the creation of fabrication drawings directly from the Plant 3D model. It can automatically generate orthographic and isometric views, dimensions, annotations, information tables, and drawing frames, with batch output to PDF or DWG. In an assumed workflow, drawing creation time can be reduced from 30 minutes to 5 minutes per drawing—an 83% reduction.*
ASPO Spool Manager helps streamline spool preparation by visualizing Shop and Field welds in 3D and using rule-based automation to assign Shop/Field welds, spool numbers, and weld numbers. Engineers can then adjust the results directly on the model while maintaining data consistency and checking for issues before drawing output.
Through demonstrations of both solutions, you will see how ASPO can help teams move from manual drawing and data-entry work toward a more automated, model-based fabrication workflow—without losing the value of the 3D data already created during design.
*Based on Arent's assumed workflow and project conditions. Actual results may vary depending on support configuration and operating environment.
